AMZINST

Head Trinocular head, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5 ● Eyepiece WF10X/18mm, insert dia. 23.2mmWF10X/20mm, insert dia. 23.2mmWF16X/13mm, insert dia. 23.2mmWF25X/8mm,  insert dia. 23.2mm ●●໐໐໐ DIN Achromatic Objective 4x N.A.0.10, W.D.=18.6mm 10x N.A.0.25, W.D.=6.5mm 40x(S) N.A.0.65, W.D.=0.47mm 100x(S, Oil) N.A.1.25, W.D.=0.07mm ● ● ● ●...

Order NO. Mag NA Work Distance 270-IPA4X 4X 0.10 19.37MM 270-IPA10X 10X 0.25 15.86MM 270-IPA20X 20X 0.40 1.04MM 270-IPA40X 40X 0.65 0.67MM 270-IPA40XL L-40X 0.68 2.8MM 270-IPA60X 60X 0.80 0.50MM 270-IPA100X 100X 1.25 0.25MM For NK-270T Series Upright Biological Microscope

ACCESSORIESNUMBER ITEM SPECIFICATION NK-270B NK-270T 270-BH 270-TH Head Siedentopf binocular, 45° inclined, 360° rotatable, interpupillary distance 52-76mm, left diopter adjustment ±5Siedentopf trinocular, 45° inclined, 360° rotatable, interpupillary distance 52-76mm, left diopter adjustment ±5 ● ๐ ๐ ● 270-10EX Eyepiece PL10X/22mm ●● ●● 270-IA4X 270-IA10X 270-IA20X 270-IA40X 270-IA60X 270-IA100X Infinity Achromatic...

ACCESSORIES NUMBER ITEM SPECIFICATION NK-270B NK-270T 270-BH  270-TH  Head "Siedentopf binocular, 45° inclined, 360° rotatable, interpupillary distance 52-76mm, left diopter adjustment ±5" "Siedentopf trinocular, 45° inclined, 360° rotatable, interpupillary distance 52-76mm, left diopter adjustment ±5" ●  ๐  ๐  ●  270-10EX Eyepiece PL10X/22mm ●● ●● 270-IA4X 270-IA10X 270-IA20X 270-IA40X 270-IA60X 270-IA100X Infinity Achromatic Objectives...

Feature- Full-view 11.6" high-definition LCD screen- Inter newest GLK platform- A variety of peripheral interfaces- Windows 10 64-bit enterprise version system- Built-in 5M/16M high-resolution imaging system-Built-in powerful measurement and analysis software system   Specification 270-TH Head "Siedentopf trinocular, 45° inclined, 360° rotatable, interpupillary distance 52-76mm, left diopter adjustment ±5" ● 270-10EX...

        NK-300B NK-300T NK300-BH NK300-TH82 NK300-TH100 Head Seidentopf Binocular Head, Inclined 30°, rotatable 360°, Interpupillary distance 48mm-75mm Seidentopf Trinocular Head: Inclined 30°, rotatable 360°, Interpupillary distance 48mm-75mm, light split ratio 80:20 Seidentopf Trinocular Head: Inclined 30°, rotatable 360°, Interpupillary distance 48mm-75mm, light split ratio 0:100 ● ໐ ໐...

Items Specification NK-350B NK-350T Head Siedentopf binocular body, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5 Siedentopf trinocular body, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, left diopter adjustment ±5 ●   ໐   ໐   ●   Eyepieces WF10X/18mm WF25X ●● ●● ●● ●● Nosepiece Quadruple inward revolving ● ● Achromatic objectives...

Items Specification NK-350B NK-350T Head Siedentopf binocular body, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5 Siedentopf trinocular body, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, left diopter adjustment ±5 ●   ໐   ໐   ●   Eyepieces WF10X/18mm WF25X ●● ●● ●● ●● Nosepiece Quadruple inward revolving ● ● Achromatic objectives...

ACCESSORIESNUMBER ITEM SPECIFICATION NK-360B NK-360T / Optical system Antifungal brightfield infinity optical system ● ● 360-HB 360-HT   Viewing Head Binocular tube, 30° inclined, 360°rotatable, interpupillary distance 46-75mm Trinocular tube, 30° inclined, 360°rotatable, interpupillary distance 46-75mm, Light spliting ratio: 50:50 ●  ໐   ໐  ●   360-10EX 360-10EXP 360-16EX Eyepiece PL10X/22mm With diopter adjustment ±5,...

ACCESSORIESNUMBER ITEM SPECIFICATION NK-360B NK-360T / Optical system Antifungal brightfield infinity optical system ● ● 360-HB 360-HT   Viewing Head Binocular tube, 30° inclined, 360°rotatable, interpupillary distance 46-75mm Trinocular tube, 30° inclined, 360°rotatable, interpupillary distance 46-75mm, Light spliting ratio: 50:50 ●  ໐   ໐  ●   360-10EX 360-10EXP 360-16EX Eyepiece PL10X/22mm With diopter adjustment ±5,...

ACCESSORIESORDER ITEM SPECIFICATION NK-50B NK-50T APM50-BH30 APM50-BT30 APM50-TH30 APM50-TT30 Head Seidentopf binocular head, inclined 30° , Interpupillary 48-75mm Tilting seidentopf binocular head, Inclined 5 -35°, Interpupillary 48-75mm Seidentopf trinocular head, inclined 30°, interpupillary 48~75mm, Light Split 100:0 or 0:100 Tilting seidentopf trinocular head, Inclined 5 -35°, Interpupillary 48-75mm, Light Split...

ACCESSORIESNUMBER     NK-710B NK-710T NK-720B NK-720T NK-720TU NK710-BHE   NK710-THE   NK710-THER     NK710-HE5M   NK710-HE5M   NK710-HE16M   Head Binocular head, 30° inclined, interpupillary distance: 47-78mm Trinocular head, 30° inclined, interpupillary distance: 47-78mm Trinocular Head, 30° Inclined, interpupillary 47-78mm, splitting ratio 50/50 (100/0 or 0/100 is optional) 30° inclined, interpupillary distance: 47mm-78mm; 5MP 30° inclined, interpupillary...

● Screen Size: 7-inch IPS Screen● Screen resolution: 1024*600● Sensor: 1/2.8" CMOS● Active Recording Pixels: 2.0 Mega-pixel● Pixel Size: 2.0 x 2.0µm● Sensor resolution: 1024(H)*1080(V)● Nosepieces: Triple nosepiece● DIN Achromatic Objective:  - 4x/ 0.10  - 10x/ 0.25  - 40x(S)/ 0.65● Stage: Double layer 95*105mm mechanical stage, travel distance 50*20mm, with...

● Head: Monocular head, 45° inclined, 360° rotatable,● Eyepiece: WF10X/16mm● Achromatic Objectives:   - 4X/0.1,  - 10X/ 0.25  - 40Xs/ 0.65● Nosepiece: Triple nosepiece● Stage: Double layer 95*105mm mechanical stage, travel distance 55*15mm, with caliper● Condenser: NA 0.65 ● Focusing: coaxial coarser & fine adjustment● Illumination: incident & transmitted LED light, brightness...

● Head: Binocular head, 45° inclined, 360° rotatable, interpupillary distance 54-75mm● Eyepiece: WF10X/16mm● Achromatic Objectives:   - 4X/0.1,  - 10X/ 0.25  - 40Xs/ 0.65● Nosepiece: Triple nosepiece● Stage: Double layer 95*105mm mechanical stage, travel distance 55*15mm, with caliper● Condenser: NA 0.65 ● Focusing: coaxial coarser & fine adjustment● Illumination: incident & transmitted...

● Head: Monocular head, 45° inclined, 360° rotatable● Eyepiece: WF10x/16mm● Objectives: Achromatic 4x 10x 40Xs ● Nosepiece: Triple nosepiece● Stage: Double layer mechanical stage 95x105mm● Condenser: NA 0.65 with disc diaphragm● Focusing: coaxial coarser & fine adjustment● Illumination: incident & transmitted LED light, brightness adjustment   Optional Accessories:- 10x/16mm eyepieces (SKU: NK-10EXZ)- 16x eyepieces...
