● Head: binocular head interpupilary distance adjustment range 48-75mm● Eyepiece: WF10X● Infinity plan achromatic objectives: 4x, 10x, 40xs, 100xs(oil)● Nosepiece: quadruple nosepiece● Condenser: abbe condenser NA1.25 with diaphragm filter● Focusing: coaxial coarse and fine adjustment, fine division 0.002mm, coarse stroke 30mm● Stage: double layers mechanical stage, 140x140mm/75x45mm● Illumination: built in...

    NK-210A NK-210B NK-210T Head Monocular head, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5 Binocular head, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5 Trinocular head, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5   ●       ...

    NK-210A NK-210B NK-210T Head Monocular head, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5 Binocular head, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5 Trinocular head, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5   ●       ...

    NK-210A NK-210B NK-210T Head Monocular head, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5 Binocular head, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5 Trinocular head, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5   ●       ...

Head Trinocular head, 30° inclined, 360° rotatable, interpupillary distance 48-75mm, Left diopter adjustment ±5 ● Eyepiece WF10X/18mm, insert dia. 23.2mmWF10X/20mm, insert dia. 23.2mmWF16X/13mm, insert dia. 23.2mmWF25X/8mm,  insert dia. 23.2mm ●●໐໐໐ DIN Achromatic Objective 4x N.A.0.10, W.D.=18.6mm 10x N.A.0.25, W.D.=6.5mm 40x(S) N.A.0.65, W.D.=0.47mm 100x(S, Oil) N.A.1.25, W.D.=0.07mm ● ● ● ●...

The NK-220 series microscope is an upright biological microscope from AMZ Instruments. It have, monocular, binocular,  trinocular viewing head and offers magnification options of 40x, 100x, 400x, 1000x, 1600x, 2500x. The microscope also features a built-in LED illumination system that provides bright and consistent lighting. It is ideal for applications...

.The NK-220 series microscope is an upright biological microscope from AMZ Instruments. It have, monocular, binocular, trinocular viewing head and offers magnification options of 40x, 100x, 400x, 1000x, 1600x, 2500x.The microscope also features a built-in LED illumination system that provides bright and consistent lighting. It is ideal for applications such...

The NK-220 series microscope is an upright biological microscope from AMZ Instruments. It have, monocular, binocular, trinocular viewing head and offers magnification options of 40x, 100x, 400x, 1000x, 1600x, 2500x.The microscope also features a built-in LED illumination system that provides bright and consistent lighting. It is ideal for applications such...

ACCESSORIESNUMBER ITEM SPECIFICATION NK-230ET NK-230T NK230-30HEB Binocular Tube Siedentopf, Inclined 30°, rotatable 360°, interpupillary distance 48-75mmdiopter adjustment (Both side) ໐ ໐ NK230-30HET Trinocular Tube Siedentopf, inclined 30°, rotatable 360°, interpupillary distance 48-75mm, light distribution 20:80, diopter adjustment (Both side) ● ● NK230-HE3M NK230-H5M Digital Tube 3MP digital head, 1/2’’CMOS color...

ACCESSORIESNUMBER ITEM SPECIFICATION NK-230FAB NK-230FPB NK230-30HEB Binocular Tube Siedentopf, Inclined 30°, rotatable 360°, interpupillary distance 48-75mmdiopter adjustment (Both side) ● ● NK230-30HET Trinocular Tube Siedentopf, inclined 30°, rotatable 360°, interpupillary distance 48-75mm, light distribution 20:80, diopter adjustment (Both side) ໐ ໐ NK230-HE3M NK230-H5M Digital Tube 3MP digital head, 1/2’’CMOS color...

ACCESSORIESNUMBER ITEM SPECIFICATION NK-230FE NK-230B NK230-30HEB Binocular Tube Siedentopf, Inclined 30°, rotatable 360°, interpupillary distance 48-75mmdiopter adjustment (Both side) ● ● NK230-30HET Trinocular Tube Siedentopf, inclined 30°, rotatable 360°, interpupillary distance 48-75mm, light distribution 20:80, diopter adjustment (Both side) ໐ ໐ NK230-HE3M NK230-H5M Digital Tube 3MP digital head, 1/2’’CMOS color...

● Head: binocular, inclined at 45° interpupillary 48mm-75mm● Eyepiece: WF10x/20mm● Achromatic objective: 4x, 10x, 40x, 100x● Nosepiece: backward quadruple nosepiece● Abbe Condenser: NA1.25 with Diaphragm, Filter● Focusing: coaxial coarse and fine adjustment, fine division 0.001mm, coarse stroke 37.7mm/rotation, fine division 0.1mm/rotation, coarse stroke 24mm● Stage: double layer mechanical stage 142x132mm,...

● Head: Trinocular, inclined at 45° interpupillary 48mm-75mm● Eyepiece: WF10x/20mm● Achromatic objective: 4x, 10x, 40x, 100x● Nosepiece: backward quadruple nosepiece● Abbe Condenser: NA1.25 with Diaphragm, Filter● Focusing: coaxial coarse and fine adjustment, fine division 0.001mm, coarse stroke 37.7mm/rotation, fine division 0.1mm/rotation, coarse stroke 24mm● Stage: double layer mechanical stage 142x132mm,...

● Head: Binocular, Inclined at 30º, Interpupillary 48-75mm, 360° Rotatable● Eyepiece: WF10x/F.N.22mm, Dia.30mm, High Eyepoint, Diopter Adjustment -/+5● Objective: Infinity plan achromatic objective: 4x, 10x, 40x, 100x ● Nosepiece: backward quadruple nosepiece● Condenser: Abbe Condenser NA1.25, with Iris Diaphragm, Center Adjustable● Focusing: Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse...

● Head: Trinocular, Inclined at 30º, Interpupillary 48-75mm, 360° Rotatable● Eyepiece: WF10x/F.N.22mm, Dia.30mm, High Eyepoint, Diopter Adjustment -/+5● Objective: Infinity plan achromatic objective: 4x, 10x, 40x, 100x ● Nosepiece: backward quadruple nosepiece● Condenser: Abbe Condenser NA1.25, with Iris Diaphragm, Center Adjustable● Focusing: Coaxial Coarse and Fine Adjustment, Fine Division 0.002mm, Coarse...

● Head: monocular, inclined at 45°, 360°rotatable● Eyepiece: WF10x/18mm● Achromatic objectives: 4x, 10x, 40xs, 100xs(oil)● Nosepiece: quadruple nosepiece● Condenser: abbe condenser NA1.25 with diaphragm filter● Focusing: coaxial coarse and fine adjustment, moving range 22mm● Stage: double layer mechanical stage 140x130mm● Illumination: LED illumination brightness adjustment● Product single size: 25x21.5x37cm

● Head: binocular, inclined at 45°, 360°rotatable● Eyepiece: WF10x/18mm● Achromatic objectives: 4x, 10x, 40xs, 100xs(oil)● Nosepiece: quadruple nosepiece● Condenser: abbe condenser NA1.25 with diaphragm filter● Focusing: coaxial coarse and fine adjustment, moving range 22mm● Stage: double layer mechanical stage 140x130mm● Illumination: LED illumination brightness adjustment● Product single size: 25x21.5x37cm

● Head: trinocular, inclined at 45°, 360°rotatable● Eyepiece: WF10x/18mm● Achromatic objectives: 4x, 10x, 40xs, 100xs(oil)● Nosepiece: quadruple nosepiece● Condenser: abbe condenser NA1.25 with diaphragm filter● Focusing: coaxial coarse and fine adjustment, moving range 22mm● Stage: double layer mechanical stage 140x130mm● Illumination: LED illumination brightness adjustment● Product single size: 25x21.5x37cm

● Eyepieces magnification: 25x● Lens material: Achromatic glass● Eyepiece diameter for eyepiece tube: 23mm● For a biological microscope with an eyepiece diameter of 23mm (NK-210B, NK-210T, NK-220A, NK-220B, NK-220T)

Order NO. Mag NA Work Distance 270-IPA4X 4X 0.10 19.37MM 270-IPA10X 10X 0.25 15.86MM 270-IPA20X 20X 0.40 1.04MM 270-IPA40X 40X 0.65 0.67MM 270-IPA40XL L-40X 0.68 2.8MM 270-IPA60X 60X 0.80 0.50MM 270-IPA100X 100X 1.25 0.25MM For NK-270T Series Upright Biological Microscope
